Control panel

Buttons and fields

General buttons
'ON/OFF' and 'Home' button
The button-position in the lower left corner of the
home view represents two functions:
• The 'ON/OFF' button ...
is accessible from the home view only and:
displays the buttons for 'Heating - Power
ON/OFF' and 'Reinitializing' when pressed.
See detailed description of buttons below.
- flashes when the 'Heating - Power ON'
button has been activated until set
temperature for the heated roller and catox
is reached.
• The 'Home' button ...
Accessible from all other views except the
'Home' view:
- switches view to the home view from any
sub view when pressed, and at the same
time the 'Home' button will be replaced by
the 'ON/OFF' button described above.
'Heating - Power ON/OFF' buttons
• Accessible from 'Heating - Power ON/OFF'
view only (See the 'ON/OFF' and 'Home'
buttons above).
• The 'Heating - Power ON' button activates
heating of the heated roller and catox. Heating
up takes approx. 40 min. See also description
of "Starting up" on page 2-1.
• The 'Heating - Power OFF' button deactivates
heating of the heated roller and catox. Cooling
down takes approx. 40 min. See also
description of "Shutting down" on page 2-4.
January, 2020
ON/OFF button
HOME button
Heating - Heating -
Power ON Power OFF button
button
