D4 Driver 350
D4 Series Wall-Mount Driver Installation
C
D
B
A
A
Power input
B
Output channels
C
Antenna*
D
DMX input and thru (RJ45)
DMX input and thru (eight-pin terminal
E
blocks)†
*The antenna is not present on RDM models.
†Eight-pin terminal blocks are not present on D4
Driver 150.
