D4 Series Wall-Mount Driver Installation

This section provides information on how to install wall-mount D4 Series constant current
(CC) and constant voltage (CV) drivers. The D4 Constant Current Driver can control up to four
ArcSystem Pro One-Cell or Pro One-Cell Small luminaires. Up to 32 drivers can be installed on
one hard-wired line of DMX.

Electrical and Wiring Specification

WARNING:
disconnect device cannot be serviced or operated safely.
AVERTISSEMENT :
installés sans qu'un dispositif de déconnexion de l'alimentation ne soit
accessible.
Install the D4 Driver on a power distribution system with reliably identified earthed neutral and
install a maximum 15 A circuit breaker on the line conductor.
ETC recommends installing all wiring to and from wall-mount drivers in grounded metal conduit.
The wall-mount D4 Driver accepts 100–277 VAC (150 models) or 100–240 VAC (350 and 700
models), 50/60 Hz. Emergency models only: requires normal sense and maintained (emergency)
input power.
D4 Series Wall-Mount Driver Installation
Circuits that are installed without an accessible power
Il est imprudent d'utiliser ou de réparer les circuits
15
