7.6 Trip Codes

Code Description
255 No trip
1 Excess start time
2 Motor overload
3 Motor thermistor
4 Current imbalance
5 Frequency
6 Phase sequence
7 Overcurrent
8 Power loss
9 Undercurrent
10 Heat sink overtemperature
11 Motor connection
12 Input A trip
13 FLC too high
14 Unsupported option (function not available in inside delta)
15 Communications card fault
16 Network communication
18 Overvoltage
19 Undervoltage
23 Parameter out of range
20 Motor overload
24 Input B trip
26 L1 phase loss
27 L2 phase loss
28 L3 phase loss
29 L1-T1 shorted
30 L2-T2 shorted
31 L3-T3 shorted
33 Time-overcurrent (bypass overload)
34 SCR overtemperature
35 Battery/clock
36 Thermistor circuit
