7.4 Parameter Management (Read/Write)

The PROFINET Module can read parameter values from and
write parameter values to the soft starter. The module
handles 1 parameter at a time.
The device references parameters according to their
position in the soft starter's parameter list.
7 7
•
Parameter number 1 corresponds to parameter
1-1 Motor Full Load Current.
•
The VLT
parameters. Parameter 112 corresponds to
parameter 20-6 Pedestal Detect.
CAUTION
UNPREDICTABLE BEHAVIOR
Changing the values in parameter group 20-** Factory
Parameters may cause unpredictable behavior in the soft
starter.
•
Do not change the default values of the
parameters in parameter group 20-** Factory
Parameters.

7.4.1 Output

Use output bytes 2–5 to read or write a parameter to the
soft starter.
Byte Bits Details
2 0–7 Parameter number to read/write.
3 0 Reserved.
1 1 = Read parameter.
2 1 = Write parameter.
3–7 Reserved.
4 0–7 Low byte parameter value to write to soft starter/zero
data values for read.
5 0–7 High byte parameter value to write to soft starter/
zero data values for read.
Table 7.8 Structure of Master to Slave Output Bytes
14
PROFINET Module
Bits Details
®
Soft Starter MCD 500 has 112
Danfoss A/S © 11/2017 All rights reserved.

7.4.2 Input

Parameter management data from the soft starter is
reported in input bytes 60–53.
Byte Bits Details
60 0–7 Echo parameter number.
61 0 1 = Invalid parameter number.
1 1 = Invalid parameter value.
2–7 Reserved.
62 0–7 Low byte parameter value read from the soft starter.
63 0–7 High byte parameter value read from the soft starter.
Table 7.9 Structure of Master to Slave Input Bytes

7.5 Trip Codes

Trip codes are reported in registers 30241 and 30254
(standard mode) and register 40604 (legacy mode).
Trip Description
code
0 No trip
1 Excess start time
2 Motor overload
3 Motor thermistor
4 Current imbalance
5 Frequency
6 Phase sequence
7 Instantaneous overcurrent
8 Power loss
9 Undercurrent
10 Heat sink overtemperature
11 Motor connection
12 Input A trip
13 FLC too high
14 Unsupported option
(function not available in
inside delta)
15 Soft starter communication
(between device and soft
starter)
16 Network communication
(between device and soft
starter)
17 Internal fault x (where x is
the fault code detailed in
Table 7.11)
23 Parameter out of range
25 Bypass fail (bypass
contactor)
26 L1 phase loss
27 L2 phase loss
28 L3 phase loss
29 L1-T1 short-circuited
