  • Page 1 Installation Guide DeviceNet Card VLT® Soft Starter MCD 600...

  • Page 3: Table Of Contents

    Preparations DeviceNet Network Settings Enabling Network Control DeviceNet Polled I/O Structure 3.4.1 Output and Input Data 4 Troubleshooting Trip Codes 5 Parameter Handling Parameter Object 6 Specifications Connections Settings Power Certification Danfoss A/S © 2018.10 AQ277154750780en-000102 / 175R1182 | 3...

  • Page 4: Safety

    The installer is responsible for following all instructions in this manual and for following correct electrical practice. Use all internationally recognized standard practice for RS485 communication when installing and using this equipment. 4 | Danfoss A/S © 2018.10 AQ277154750780en-000102 / 175R1182...

  • Page 5: Installation

    2.2 Connecting to the Network Prerequisites: The expansion card must be installed in the soft starter. Procedure 1. Connect field wiring via the 5-way connector plug. The DeviceNet card is powered via the connector. Danfoss A/S © 2018.10 AQ277154750780en-000102 / 175R1182 | 5...

  • Page 6: Feedback Leds

    2.3.1 Module and Network LEDs The Module LED indicates the condition of the power supply and device operation. The Network LED indicates the status of the communication link between the device and the network Master. 6 | Danfoss A/S © 2018.10 AQ277154750780en-000102 / 175R1182...
  • Page 7 Online and allocated to a Master Red flashing One or more timed-out I/O connections Failed communication between device and Master Red/green flashing Communication failed and received an Identity communication failed request. Danfoss A/S © 2018.10 AQ277154750780en-000102 / 175R1182 | 7...

  • Page 8: Configuration

    Once the soft starter, device, and Master have been set up, configured, and powered up, the Master transmits 2 bytes of data to the device and receives 14 bytes of data from the device. 8 | Danfoss A/S © 2018.10 AQ277154750780en-000102 / 175R1182...

  • Page 9: Output And Input Data

    1=Starting, Running, Stopping, or Jogging Reserved Ready 0=Start or stop command not acceptable 1=Start or stop command acceptable Operating mode 0=Programming mode 1=Operating mode Command source 0=Remote LCP, Digital input, Clock 1=Network At reference 1=Running Danfoss A/S © 2018.10 AQ277154750780en-000102 / 175R1182 | 9...
  • Page 10 Power high nibble, scaled by power scale 4–5 Power scale 0=Multiply power by 10 to get W 1=Multiply power by 100 to get W 2=Power (kW) 3=Multiply power by 10 to get kW 6–7 Reserved 10 | Danfoss A/S © 2018.10 AQ277154750780en-000102 / 175R1182...
  • Page 11 For all inputs, 0=open, 1=closed (shorted) 0=Start/stop 1=Reserved 2=Reset 3=Input A 4=Input B 5–7 Reserved For models MCD6-0063B and smaller, the current reported via communications registers is 10 times greater than the actual value. Danfoss A/S © 2018.10 AQ277154750780en-000102 / 175R1182 | 11...

  • Page 12: Troubleshooting

    FLC out of range EEPROM fail (parameter out of range) Motor thermistor Excess start time Motor connection Internal fault Input B trip Communications card fault Forced network trip (Network communication (between device and network)) 12 | Danfoss A/S © 2018.10 AQ277154750780en-000102 / 175R1182...
  • Page 13 SCR firing fail L2 SCR firing failL3 VZC fail L1 VZC fail L2 VZC fail L3 Low control volts 170–182 Internal fault X. Contact the local supplier with the fault code (X). Danfoss A/S © 2018.10 AQ277154750780en-000102 / 175R1182 | 13...

  • Page 14: Parameter Handling

    Parameter object class Instance 1–xxx xxx = maximum soft starter parameter number Attribute ID Always 0x01 Get service Read single soft starter parameter value Set service Write single soft starter parameter value 14 | Danfoss A/S © 2018.10 AQ277154750780en-000102 / 175R1182...

  • Page 15: Specifications

    31 mA @ 11 V DC Galvanically isolated 1.8 A maximum for 2 ms 6.4 Certification IEC 60947-4-2 EN 60947-4-2 RoHS Compliant with EU Directive 2011/65/EU CONFORM AN CE TESTED Illustration 3: ODVA Danfoss A/S © 2018.10 AQ277154750780en-000102 / 175R1182 | 15...
  • Page 16 Installation Guide | DeviceNet Card Index Index Connector plug Data structure Input Output EDS file Expansion card Expansion port cover I/O data Module LED Network LED Parameter object Tools Flat-bladed screwdriver 16 | Danfoss A/S © 2018.10 AQ277154750780en-000102 / 175R1182...
  • Page 17 Installation Guide | DeviceNet Card Danfoss A/S © 2018.10 AQ277154750780en-000102 / 175R1182 | 17...
  • Page 18 Installation Guide | DeviceNet Card 18 | Danfoss A/S © 2018.10 AQ277154750780en-000102 / 175R1182...
  • Page 19 Installation Guide | DeviceNet Card Danfoss A/S © 2018.10 AQ277154750780en-000102 / 175R1182 | 19...
  • Page 20 Danfoss can accept no responsibility for possible errors in catalogues, brochures and other printed material. Danfoss reserves the right to alter its products without notice. This also applies to products already on order provided that such alterations can be made without subsequential changes being necessary in specifications already agreed. All trademarks in this material are property of the respective companies.
