Trip Codes

7. Trip Codes
Trip
Code Trip Name
1 Excess start time
2 Motor overload (thermal model)
3 Motor thermistor
4 Current imbalance
5 Frequency (Mains supply)
6 Phase sequence
7 Instantaneous overcurrent
8 Power loss (Power circuit)
9 Undercurrent
10 Heatsink overtemperature
11 Motor connection
12 Input A trip (Auxiliary input A)
13 FLC too high (FLC out of range)
14 Unsupported option (Not available in 6-wire)
15 Starter communication
16 Network communication
17 Internal fault
23 EEPROM fail
26 L1 phase loss
27 L2 phase loss
28 L3 phase loss
29 L1-T1 Shorted
30 L2-T2 Shorted
31 L3-T3 Shorted
33 Time-overcurrent (Bypass overload)
35 Battery/clock
36 Thermistor circuit
255 No trip
