7.5 Trip Codes

Code Description
0 No trip
1 Excess start time
2 Motor overload
3 Motor thermistor
4 Current imbalance
5 Frequency
6 Phase sequence
7 Instantaneous overcurrent
8 Power loss
9 Undercurrent
10 Heat sink overtemperature
11 Motor connection
12 Input A trip
13 FLC too high
14 Unsupported option (function not available in inside delta)
15 Starter communication (between device and soft starter)
16 Network communication (between device and soft starter)
17 Internal fault
23 Parameter out of range
25 Bypass fail (bypass contactor)
26 L1 phase loss
27 L2 phase loss
28 L3 phase loss
29 L1-T1 shorted
30 L2-T2 shorted
31 L3-T3 shorted
