8.3.3.2 Status Codes for Acyclic Services

Table 8: Status Codes Returned in Response to Get/Set Attribute Single
Status code
Status name
00d (0x00)
Success
03d (0x03)
Invalid parameter value
05d (0x05)
Path destination unknown
08d (0x08)
Service not supported
09d (0x09)
Invalid attribute value
15d (0x0E)
Attribute not settable
20d (0x14)
Attribute not supported
22d (0x16)
Object does not exist

8.4 Trip Codes

Code
Description
0
No trip
11
Input A trip
20
Motor overload
21
Heat sink overtemperature
23
L1 phase loss
24
L2 phase loss
25
L3 phase loss
26
Current imbalance
28
Instantaneous overcurrent
29
Undercurrent
50
Power loss
54
Phase sequence
55
Frequency
60
Unsupported option (function not available in inside delta)
61
FLC too high
62
Parameter out of range
70
Miscellaneous
Danfoss A/S © 2022.10
Details
This code is returned when:
the register mapped for "Get Attribute Single" is successfully read.
the register mapped for "Set Attribute Single" is successfully set.
The mapped register does not exist.
The requested service is not available for this object class/instance.
This code only applies to the service Set Attribute Single. It is returned if the value is
out of range of the mapped register.
This code only applies to the service Set Attribute Single. It is returned if the mapped
register is read-only.
The attribute specified in the request is not supported.
The object specified does not exist in the device.
