Universal Space PIN SETTER Operation Manual page 21

Pin Setter Manual
Step 2 Wrap around and tighten the nylon wiring as red area indicated. Cut the unnecessary part.
8.3.2 Making the Bowling pin bottom assy.
If you already get this part and the problem happens again, please replace the string.
No Part No
1 P135-513-000 25108030001
Step 1 Disassemble the Bowling pin
bottom assy.
Step 2 Follow instruction and tie the knots. (Figure-eight knot)
20
12/29/2017
Code Name
String
Step 2
parts together as picture.
Use the new string to bunch the
String lock
Pin bottom
fixed plate
Fastener
