IPDialog SIP Tone II (ST201)

To complete the automatic configuration on IP Dialog SIP Tone II, reset the phone to factory default
settings and enable the auto-configuration via built-in web server (by default the phone is not in auto-
provisioning mode).
To perform a factory reset:
1. Press the MENU/HANGUP key on the keypad of the phone to access the main configuration
menu.
2. Press 3, then 2 to enter the Settings and the Phone Settings menus, respectively.
3. Press 2 to select the Config phone menu.
4. Press 4, then 2 to enter the Reset and Defaults menus, respectively.
5. Press 1 to select the Restore Defaults item and confirm the restore by pressing 1.
Please note: Use the VOL keys to navigate within the menus. To select the menu item, dial the
number associated with it. For example, the short way to perform the factory reset is to consecutively
dial: 3 2 2 4 2 1 1, or in a more detailed way:
3) Settings 2) Phone Settings 2) Config Phone 4) Reset 2) Defaults 1) Restore Defaults 1) Yes.
To enable the auto-configuration on the phone
Access the configuration web site on the phone's built-in web server. To do this, open a browser
1.
on a computer that is on the LAN of the Quadro and enter the phone's IP address into the
address bar of the browser. The IP address of the phone may be viewed by pressing the
INFO/MUTE key on the keypad of the phone. The phone will require the username and the
password to allow access to its configuration. Enter the username (admin) and the password
(the default is admin) and press OK. The configuration web site of the phone can also be
accessed from the Quadro's IP Line Settings page. Click on the Web link corresponding to the
IP line attached to the extension.
2. On the configuration web site of the phone's built-in web server (see Figure 5), click on the
Advanced tab to access the advanced settings.
3. Scroll to Auto-config profile and select Profile-C from the list to enable auto-configuration.
4. Select the Auto-config every boot checkbox to allow the automatic download of the
configuration files every time the phone boots (recommended), otherwise, it loads the file
whenever the commit button on the web page is clicked.
5. Press the Commit changes button and wait until the phone downloads the configuration
settings. The LCD of the phone will display the username of the extension, but the status will
still be unregistered.
6. Click on the Servers tab, select the Register through proxy checkbox (see Figure 6), and
press the Commit changes button. Wait until the phone registers.
