1. No current measurement or an external MCU current measurement: The XAM is bypassed,
thus the MCU and peripherals are supplied directly by the regulator. Set both jumpers (MCU and
I/O) in the "BY-PS(BYPASS)" position. In this configuration, it is also possible to connect an
external measurement tool with the Xplained Pro MCU power measurement header to measure
MCU current directly instead of using the XAM.
2. MCU current measurement: The XAM measures only the MCU current while the peripherals are
supplied directly by the regulator. For this configuration, place the jumper for "I/O" (peripherals) into
the "BY-PS(BYPASS)" position and the "MCU" into the "MEAS (MEASURE)" position.
3. Peripherals measurement: The XAM measures only the peripherals current while the MCU is
directly supplied by the regulator. For this configuration, place the jumper for "MCU" into the "BY-
PS(BYPASS)" position and the "I/O" jumper into the "MEAS (MEASURE)" position.
4. MCU and peripherals measurement: In this configuration, both the MCU and peripherals are
measured by the XAM. Place both jumpers on the "I/O" and "MCU" headers in the "MEAS
(MEASURE)" position.
4.5

Kit Modifications

The SAM R30 Xplained Pro contains several resistors that can be used to disconnect I/O pins of the
ATSAMR30G18A SoC from connectors and on-board ICs, and to disconnect power signals.
Table 4-16. Zero Ohm Resistors
Design
ator
R322
R323
R324
R310
R311
R312
R313
R314
R315
R316
R317
R318
R319
R320
R321
©
2017 Microchip Technology Inc.
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
Value From
0R EDBG SWDIO
0R EDBG SWDCLK
0R EDBG TARGET RESET
0R EDBG SPI SS
0R EDBG SPI SCK
0R EDBG SPI MOSI
0R EDBG SPI MISO
0R EDBG DGI SDA
0R EDBG DGI SCL
0R EDBG CDC RX
0R EDBG CDC TX
0R EDBG DGI_GPIO0
0R EDBG DGI_GPIO1
0R EDBG DGI_GPIO2
0R EDBG DGI_GPIO3
To Comment
PA31 SWDIO Debug interface from the EDBG to
the ATSAMR30G18A
PA30 SWCLK
TARGET MCU
RESET
PA27 GPIO EDBG CDC and DGI interfaces to
the ATSAMR30G18A
PB23 SPI SCK
PB22 SPI MOSI
PB02 SPI MISO
PA16 I2C SDA
PA17 I2C SCL
PA04 UART TX
PA05 UART RX
PA08 GPIO
PA09 GPIO
PA12 GPIO
PA14 GPIO
