Pin Number
13
14
15
16
17
18
19
20
3.5.2
Xplained Pro Power Header
The power header can be used to connect external power to the SAM R30 Xplained Pro kit. The kit
automatically detects and switches to any external power if supplied. The power header can also be used
to supply power to external peripherals or extension boards. Ensure that the total current does not
exceed the recommended current limit of the on-board regulator when using the 3.3V pin.
Table 3-6. Xplained Pro Power Header
Pin Number
©
2017 Microchip Technology Inc.
Arrow.com.
Arrow.com.
Arrow.com.
Arrow.com.
Arrow.com.
Arrow.com.
Arrow.com.
Arrow.com.
Arrow.com.
Arrow.com.
Arrow.com.
Arrow.com.
Arrow.com.
Downloaded from
Downloaded from
Downloaded from
Downloaded from
Downloaded from
Downloaded from
Downloaded from
Downloaded from
Downloaded from
Downloaded from
Downloaded from
Downloaded from
Downloaded from
Pin Name
Description
UART_RX
Receiver pin of target device UART
UART_TX
Transmitter pin of target device UART
SPI_SS_A
Slave select for SPI. This pin should preferably not be connected to
anything else.
SPI_MOSI
SPI master out slave in pin. Always connected, bus type
SPI_MISO
SPI master in slave out pin. Always connected, bus type
SPI_SCK
SPI clock pin. Always connected, bus type
GND
Ground pin for extension boards
VCC
Power pin for extension boards
Pin Name
1
VEXT_P5V0
2
GND
3
VCC_P5V0
4
VCC_P3V3
Description
External 5V input pin
Ground pin
Unregulated 5V pin (an output, derived from one of the input
sources)
Regulated 3.3V pin (an output, used as main power supply
for the kit)
User Guide
ATSAMR30-XPRO
DS50002612A-page 13
