Figure 4-2. SAM R30 Xplained Pro Connector Overview
4.2.1 Xplained Pro Extension Headers
The SAM R30 Xplained Pro headers EXT1 and EXT3 offer access to the I/O of the MCU in order to
expand the board by connecting extensions to the board. These headers are based on the standard
extension header specified in the table below. The headers have a pitch of 2.54 mm.
Table 4-1. Extension Header EXT1
EXT1 Pin
1 [ID]
2 [GND]
3 [ADC(+)]
4 [ADC(-)]
5 [GPIO1]
6 [GPIO2]
7 [PWM(+)]
8 [PWM(-)]
9 [IRQ/GPIO]
10 [SPI_SS_B/GPIO] PA23
11 [TWI_SDA]
12 [TWI_SCL]
13 [USART_RX]
14 [USART_TX]
15 [SPI_SS_A]
16 [SPI_MOSI]
©
