Operation
To power the lamp (equipment with 2A or more power)
Be sure to fit the line with a suitable capacity contactor and fuse.
Lam p
2. Turn the time signal ON for Steps 2 and 4 of the program.
Example 2: Following is an example 5-step program that charges specimens in steps 2 and 4.
Target
temperature
Time signal
Procedure:
1. Connect the specimens to the time signal terminals and specimen power supply control terminals as
shown in the following diagrams.
T
FIGURE 6.42. IME SIGNAL TERMINAL
Fuse
E
FIGURE 6.43.
80
50
20
(°C)
ON
OFF
Step No.
1
Platinous User's Manual
(2A
OR MORE
Tim e s ignal inlet
Fuse
Power
supply
XAMPLE PROGRAM
2 3 4
)
5
