Names and Functions of Parts

4.1.3 Test Area (1)

Door Outer Gasket
(6)
Door Inner Gasket
(7)
Test Area (1)
(1) Test Area
(2) Shelf Support Pilaster
(3) Shelf Bracket
(4) Shelf
(5) Dew Tray
(6) Door Outer Gasket
(7) Door Inner Gasket
26
C
FIGURE 4.12.
Name
Area where specimens are located for temperature (&
humidity) tests.
Install shelf brackets here.
Supports the shelf. To change shelf height, reposition
the brackets on the shelf support.
Holds specimens during tests.
Collects and drains dew formed on the chamber door.
Keeps outside air from penetrating the chamber.
Keeps outside air from penetrating the chamber.
Platinous User's Manual
HAMBER TEST AREA
Shelf Support
Pilaster (2)
Shelf Bracket (3)
Shelf (4)
Dew Tray (5)
Function/Use
