Installation
B
E
The front clearance* required for opening the door is as follows:
*Projections excluded
Chamber size is given below:
I
FIGURE 5.19.
A: Min. 42" (106cm)*
B: Min. 6" (measured from top of motor cover)
C: See
D: Min. 24" (61cm)
E: Min. 24" (61cm)
D
A
C
R
EQUIRED CLEARANCE FROM CHAMBER FRONT
TABLE 5.8.
Type
2
3
4
C
HAMBER EXTERIOR SIZE
TABLE 5.9.
Type
2
3
4
Platinous User's Manual
NSTALLATION SPACE
Table 5.8 on page 37 below
ESL, ESU, ESX, ESZ
28 in. (70cm)
32 in. (80cm)
48 in. (120cm)
ESL, ESU, ESX, ESZ
36.43"W x 47.08"H x 76.15"D
41.37"W x 55.01"H x 80.08"D
57.24"W x 58.66"H x 86.11"D
*
37
