Installation

5.3.2 Primary Power Supply Connections

The chamber is connected to the primary power supply via the power cable. It is also grounded to prevent
noise from infiltrating electronic circuits and to protect users against electric shock which can result from
leakage current.
DANGER
!
resulting in electric shock. This will also leave the equipment unprotected against power supply
noise.
Procedure:
1. Remove breaker cover (See
2. Feed the power cable through the top power cable port.
3. Connect phase wires to terminals on top of breaker.
4. Connect the grounding wire of the power cable to the grounding terminal.
Power Phase Wires
40
EXPLOSION! DO NOT ground the equipment on gas pipes.
Grounding of this sort could result in explosion.
Ground the equipment PROPERLY
ELECTRICAL SHOCK! Unless the equipment is grounded, overcurrent
and short circuit protective devices cannot operate properly, possibly
Figure 4.11, "Left, rear and top," on page
P
RIMARY POWER SUPPLY CONNECTION
FIGURE 5.21.
Platinous User's Manual
24).
Grounding
Terminal
