Temperature Heat-up Rate
Temperature-Humidity Con-
trol Range
Temperature Pull-down Rate
Temperature Range
Temperature Uniformity
Test Chamber
Water-cooled Specification
(Water Cooled Condenser)
FIGURE 9.51.
t 2
t 1
The range in which temperature and humidity can be reproduced inside
the chamber. It is normally expressed as a graph with temperature as the
x-axis and humidity as the y-axis.
T
EMPERATURE
FIGURE 9.52.
100
98
90
80
60
%RH
45
40
20
0
10°C
15°C
The time required for the temperature to change from a defined tempera-
ture t1 to a defined lower temperature t2. This is simply the time required
for the drop in temperature and does not include the time it takes for the
temperature to stabilize.
T
FIGURE 9.53.
t 1
t 2
The range of temperatures that can be reproduced inside the chamber.
The difference in temperature between the geometric center of the
chamber and any arbitrary point in the effective area.
A contained ambient constructed so as to obtain a desired temperature
and humidity.
The condenser in the refrigeration circuit is cooled by water. Usually, a
cooling tower or similar unit is used to supply water and cool heat gener-
ated by the condenser. The water-cooled specification is an option with
Platinous Sterling Series Chambers.
