How to Switch Between Input Sources

Green source buttons are available for switching to output.
A blinking Green source button is the current PVW (preview) source [TBAR mode only]
The source button that is Red is the video source that is the current PGM (program) output
In FAST Mode:
Press a source button (1, 2, 3, or 4) that is green.
Selected source will be switched to the output with the set fade TIME and using the MIX transition selected, wit
h the pressed source button becoming red.
In TBAR Mode:
Press a green button to set the source as the PVW, the source button will blink green.
Slide the TBAR to switch/mix from the current PGM source to the PVW source.. Any MIX transition effect will be
applied as the TBAR is moved. Once the TBAR has been fully transitioned, the indicator lights on sources
buttons that are PGM and PVW will be swapped.
Note: Source selection is locked when TBAR is in transition (not entirely docked at a left or right position)

How to Apply a PIP

1. Decide which source to be the main picture, select and switch it to PGM when PIP is OFF
2. Select the PIP layout mode in PIP menu,switch A/B layer via the knob.
3. Select the input source and switch it to sub-picture on PGM
4. After switching, the selected green button turns to red.
after PIP mode is selected, the background can not be changed unless turn off the PIP mode and restart
the above steps.
