Edition 3 April 2012
Button 5 with yellow LED light to select UV light ON/OFF. The yellow light indicates that the UV
light is ON. (UV light and matching UV timer for radiation time are optional).
Note: For increased safety against unintended UV radiation which will harm eyes and skin: the front
window must be closed in the lowest position and normal light must be switched off before UV light
can be switched on. (See UV LIGHT MODE sub menu)
Button 6 with blue LED provides a signal to a remote source such as OPEN/CLOSE for a solenoid gas valve
(optional).
Display:

7.2 Main menu

When first powering up the cabinet the display will read:
This is normal. It simply means the mains power supply has been disconnected
at some time. If it occurs in the morning before operation then cabinet was
disconnected overnight. Check for any power interruptions that may have
occurred.
To start the cabinet press the black ENTER button ●and the display will now
show the cabinet type plus time and date, for example:
Button 7 for opening of the front window and for scrolling up in
sub menus.
Button 8 for scrolling back to previous heading in sub menu.
Button 9 for scrolling forward in sub menu.
Button 10 for lowering window and scrolling down in sub menus.
Central Black Button is ENTER button. Use this to enter any
menus and submenu headings.
◄► Left / right arrows allow movement of menu to next title
● Indicates ENTER button must be pressed to activate sub
menu.
