LaboGene Mars Service Manual page 55

Edition 3 April 2012
Model
Catalogue No.
External dimension (DxWxH)
Working chamber dimensions (DxWxH)
Net weight
Spillage, litres
Exhaust volume, ±10%
Air velocity, in-flow
Air velocity down flow, ±10%
Noise level, DIN
Light intensity variable
Supply Voltage/frequency
Power consumption
Required fusing
Input current
Socket(s) outlets
Max leakage current
Units
Support stand
Front shield
All other painted parts
Trough and tabletop
Internal main and exhaust
plenum
Damping plate
Front / Side Windows
Unit
mm
mm
kg
l
m³/h
m/s
m/s
dB(A)
Lux
V/Hz
W
A
A
V/Hz/A
mA
Material
Steel 1203 2 mm
Al Mg 3,2 mm
Steel 1203, 1,5 mm
Stainless steel AISI 304
Galvanized steel
MPM ...........
Laminated / tempered
Page 55/59
Mars/Mars Pro Service Manual
Mars 1200 GS
9.001.020.000
795x1303x1248
650x1200x720
250
18
400
≥0,4
0,3
<54db
750-2000
220/50
600
Fuse 10 A or circuit breaker 10 A
1.8
230/50/4 Max. leakage current: 1,5
mA
2 mA
Treatment
Polyester-coated RAL 9016MAT
Polyester-coated RAL 9016MAT
Polyester-coated RAL 9016MAT
Polished
2×3 mm / 1×5 mm
