FPC 6000 Web Page
1.
Open a web browser on a PC connected to the
same subnet as the FPC 6000.
2.
Enter the IP address of the FPC 6000 into the web
browser.
3.
In the dialog box that opens, enter the touchpanel
user name (by default, this is admin) and
password.
NOTES:
•
The factory configured passwords for all accounts on this device have been set to the device serial number. Passwords
are case sensitive.
•
If the device is reset to default settings, the password is reset to - extron - the default configuration.
•
To change the password, you must use the Extron Toolbelt utility (see the Toolbelt Help File). Contact your Extron
representative about obtaining a license for Toolbelt.
Operation
Login
The FPC 6000 has a
control, monitor, access, and manage a range of Extron matrix switchers over a local area network.
Login Screen
When the FPC 6000 is powered on, it opens to the login
screen.
1.
Press the Matrix IP Address text box. An
onscreen keyboard appears.
2.
Enter the IP address of the matrix switcher. If you
have previously connected to the matrix switcher,
the IP address may already be displayed, or may be
available in the drop-down menu.
3.
In the Matrix Type field, select the appropriate
type for your matrix.
4.
Press the Username text box and enter the user
name of the matrix switcher.
5.
Press the Password text box and enter the
password of the matrix switcher.
NOTE:
See the FPC 6000 User Guide for the matrix switcher for information about device passwords.
6.
Press Connect. The FPC 6000 attempts to connect to the matrix switcher.
If the connection is successful, the FPC 6000 opens to the Ties screen.
If the connection is unsuccessful, you see an error message. Check that you have the correct values for the IP address,
matrix type, username, and password before re-entering the values.
Screen, four tabs (Ties, Status,
Figure 7.
FPC 6000 Web Page
I/O
Info, Customize) and the Disconnect button, that allow you to
Figure 8.
FPC 6000 Login Screen
5
