Pre-installation and application warnings

Firmware notes: This section highlights important information for this specific firmware and will assist in
pricing accordingly, as well as bringing awareness to any operational or vehicle limitations.
T-Harness
compatible
Important! RSR installations are NOT compatible with vehicles equipped with a manual transmission.
Š
Remote Start Ready (RSR) is a function that enables the interface module to remote start the vehicle completely on its own.
Š
Consequently, there is no need for an aftermarket or an OEM remote starter in order to start the vehicle from a distance.
SmartStart Compatible: SmartStart is equipped with D2D, which means it can be connected to an interface module and
Š
used in Remote Start Ready (RSR) mode without the use of a remote starter. See "Module programming" for more information.
Key2GO is mandatory to control the immobilizer override in this fimware.
Š
The optional Plug & Play THGMD1 or THGM610D T--Harnesses are sold separately.
Š
The OBDll Diagnostic Connector features will remain the same even when the T-Harness is installed.
Š
Unless specified otherwise, all connectors are displayed from the wire side, with the exception of the OBDll diagnostic
Š
connector.
Refer to the "Vehicle connections" following the installation diagram.
Š
Heat Seat Activation is ONLY available in compatible vehicles (See "Feature programmming" for more information).
Š
General notes: This section highlights important information for this specific firmware.
If the RAP Off wire is NOT connected, the radio will turn OFF but some lights will remain ON in the center console for 10
[1]
minutes. Connect the Green/Black wire, pin 2/12 to the vehicle driver door input to avoid the issue. The RAP Off/Door
input color and location can be found in the "Vehicle connections" section.
5
403.GM10 4.16 2011 Chevrolet Cruze
© 2019-03-01 Directed. All rights reserved.
THGMD1 or THGM610D
Keys required for Keys required for
1
programming operation
0
