Vehicle connections
The connection information listed below is specific to the 2011 Chevrolet Cruze. Refer to "Pre-installation and application warnings" for a list of important notes.
Data 14-pin blue connector (H1)
Module
Conn./Pin
Color
H1/1
Light Green
H1/2
Violet/Yellow
H1/3
Tan/Black
H1/4
Tan
H1/5
Orange/Green
H1/6
Orange/Brown
H1/7
Brown
H1/8
Yellow
H1/9
Orange/Yellow
H1/10
Orange/Red
H1/11
Yellow/Red
H1/12
Brown/Red
H1/13
Red
H1/14
Black
Output 12-pin red connector (H2)
Module
Conn./Pin
Color
H2/1
Black/White
H2/2
Green/Black
H2/3
Green/White
H2/4
Red/Black
H2/5
Violet/White
H2/6
Gray
H2/7
Gray/Black
H2/8
Violet/Green
H2/9
Violet/Brown
H2/10
Yellow/Black
H2/11
Orange/Black
H2/12
Blue/Red
11
403.GM10 4.16 2011 Chevrolet Cruze
© 2019-03-01 Directed. All rights reserved.
Description
(DATA) Single Wire CAN
No Connection
(DATA) HS CAN High
(DATA) HS CAN Low
No Connection
No Connection
Relay N.O. (+) 12 Volt Input
Relay COM (+) Ignition Output
Relay N.C. No Connection
Relay N.C. Immo. Interrupt
Relay COM Immo. Interrupt
Relay N.O. No Connection
(+) 12 Volt Input
(-) Ground
Description
(-) Parking Light Output
(-) RAP Off Output [1]
No Connection
(-) Lock Output
No Connection
No Connection
(+) Accessory Output
No Connection
No Connection
No Connection
Immo. Data
(-) Unlock Output
Connects To
Wire Location
OBD-Data Link Connector, black 16 pin plug, pin 1
No Connection
OBD-Data Link Connector, black 16 pin plug, pin 6
OBD-Data Link Connector, black 16 pin plug, pin 14
No Connection
No Connection
BCM in center console front passenger side, blue 27 pin plug, pin 4
Ignition Switch, white 6 pin plug, pin 1
No Connection
Immobilizer Control Module on ignition switch, violet 3 pin plug, pin
2
Immobilizer Control Module on ignition switch, violet 3 pin plug, pin
2
No Connection
BCM in center console front passenger side, blue 27 pin plug, pin 4
Connects To
Wire Location
Headlight Switch, black 12 pin plug, pin 3
Driver Window Switch, black 8 pin plug, pin 6; Driver Window
Motor, black 7 pin plug, pin 6
No Connection
No Connection
No Connection
No Connection
Ignition Switch, white 6 pin plug, pin 3
No Connection
No Connection
No Connection
Immobilizer Control Module on ignition switch, violet 3 pin plug, pin
2
No Connection
(+/-)
Wire Color
Data
Green
Data
Blue
Data
White
+
Red/Gray (30A)
+
Violet/Black
Data
Green/Violet
Data
Green/Violet
+
Red/Gray (30A)
(chassis ground)
(+/-)
Wire Color
-
Green/Gray
-
Gray (express down
window); Gray (express
up/down window)
+
Violet/Yellow
Data
Green/Violet
