Wiring diagram with T-Harness (THGM610D Rev.1&2)
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
Ignition Barrel
To
To
Vehicle
Ignition
(violet connector
Ignition Connector
(black connector at
ignition switch)
T-01
3-pin
connectors
T-02
NOT USED
(-) Parking Lights: Pin 3, 5 or 7
1 2 3 4
7 8 9 10
Headlight Switch
(black 12-pin connector)
7 403.GM10 4.16 2011 Chevrolet Cruze
© 2019-03-01 Directed. All rights reserved.
Use connectors
labeled GM10
3-pin
To
Away from
connectors
Immobilizer
Immobilizer
Control Module
Control Module
(vehicle side)
under ignition
switch)
GM 10
GM 10
THGM610D Rev.1 & 2 (Optional T-Harness)
(-) Driver Door Trigger
Refer to the Vehicle connections section.
Refer to the
Vehicle
connections
section for the
5 6
corresponding
11 12
connector, pin
and wire color
of your vehicle.
4-pin
White
Connector
Cut away the 4-pin
connector and connect
OBDII Diagnostic
the three wires to the
(connector side view)
OBDll 16-pin connector.
HS CAN High: Pin 6
Cut
SW CAN: Pin 1
HS CAN High: Tan/Black
SW CAN: Lt. Green
HS CAN Low: Tan
HS CAN Low: Pin 14
NOT USED
GM 06
(-) Parking Lights Output : Black/White
(-) RAP Off Output: Green/Black
1 8
9 16
Hood Pin
Note: The hood pin is only required on vehicles
that are not equipped with a factory hood pin.
Remote Start Safety
Override Switch
).
D2D
only
You can connect
to either a XL202
RFTD OR a SmartStart
module. Refer to the
SmartStart/XL202
Installation Notes for
more information.
