12.4. REPLACEMENT OF GRID STAINLESS
The exit grid ensures consistency in the
dose. Located inside the coffee outlet (
), it can be replaced by following the steps
below:
1. See 12.3.1.A section
2. Remove the screws securing the
plastic cover using an Allen key No. 2.5.
3.
Remove the screw fixing the base
of aluminum siding, using an Allen key
No. 4.
ORIGINAL INSTRUCTIONS | Ref. quality process 002/03 | v. 12/02/2021 | K07173H01
12.
MAINTENANCE
4.
Remove the coffee outlet (
removing the two retaining screws using
a Philips PH2. At this point, access to
grid stainless is possible. The grid is
replaced without removing any screws.
ENSURE PLACEMENT IN CORRECT
POSITION.
), by
Fig. 19
