12.
MAINTENANCE
12.3.1.
ADJUSTING THE PARALLEL
SYSTEM
A)
Loosen the screws of the
grinding regulator (
help of a Torx T20 screwdriver,
according to (Fig.10.) For grinder models
with micrometric system PARALLEL,
before removing the grinding regulator
(
), turn the regulating brake (
) counterclockwise to free it from the
PARALLEL fixing shoe.
B)
Adjust the upper burr holder to the point
that the burrs touch - point (
the grinding regulator ( ) and match the
regulator brake with the fixing shoe.
Once the brake and the shoe are fixed,
match point 0 of the regulator with the
indicator. At that point we tighten the
3 screws with Torx T20 according to
(Fig.10).
36
ORIGINAL INSTRUCTIONS | Ref. quality process 002/03 | v. 12/02/2021 | K07173H01
) with the
). Replace
!
Locking
shoe
!
Fig. 15
Indicator
Fig. 16
Punto 0
Regulator
limit stop
