INSTRUCTION
MANUAL
COFFEE GRINDER
PKE
E6/E8
BUILT-IN SCALES

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PKE E6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Compak PKE E6

Summary of Contents for Compak PKE E6

  • Page 1 INSTRUCTION MANUAL COFFEE GRINDER E6/E8 BUILT-IN SCALES...
  • Page 2 ORIGINAL INSTRUCTIONS | QUALITY PROCESS REF. | V. 09|10|2020 | CODE K07180...

  • Page 3: Table Of Contents

    CONTENTS COFFEE GRINDER PKE E6 E8 BUILT-IN SCALES SAFETY DESCRIPTION INSTRUCTIONS IDENTIFICATION TECHNICAL CHARACTERISTICS EXTERNAL COMPONENTS INSTALLATION ADJUSTMENT OPERATION SETTINGS CLEANING MAINTENANCE DECLARATION OF CONFORMITY ORIGINAL INSTRUCTIONS | QUALITY PROCESS REF. | V. 09|10|2020 | CODE K07180...
  • Page 4 SAFETY ADDITIONAL SAFETY MEASURES BUILT-IN TO OUR GRINDERS: • Special screw to keep the hopper fixed. • Access restriction for the grinding unit. This coffee grinder should only Cleaning and maintenance be used for the function for which of the device should not be it was designed: grinding coffee carried out by children without beans.
  • Page 5 SAFETY USERS SHOULD PAY SPECIAL ATTENTION TO, AND SCRUPULOUSLY OBEY THE FOLLOWING SAFETY INSTRUCTIONS In the event of any component breaking, or for any intervention we recommend contacting a technical services centre, who will carry out Any other use will be the repair or replacement, guaranteeing considered improper that safety standards are adhered to.

  • Page 6: Pke E6 E8

    DESCRIPTION The result is a high-quality product that The equipment you have ensures the best results. purchased comes fitted with Grind by Weight technology. It has a high-precision weighing system, Our products are manufactured entirely fitted with a load cell, which is the by hand, one at a time, following the most transducer used to convert a force into demanding quality requirements.

  • Page 7: Instructions

    INSTRUCTIONS Example: ( Hopper Lid. 3.1. This manual provides the information needed for correct assembly, handling and Icons: maintenance of the device and emphasises the precautions that must be borne in mind by the operator. information Warning Equipotential To ensure you get the best out of coffee grinders, it is essential to carefully follow the instructions given in this manual.

  • Page 8: Identification

    IDENTIFICATION The technical characteristics plate is indelibly marked with the following information: NOTE: The manufacturer reserves the right to change the machine components, according to the requirements of each market, and also for technological advances. ORIGINAL INSTRUCTIONS | QUALITY PROCESS REF. | V. 09|10|2020 | CODE K07180...

  • Page 9: Technical Characteristics

    TECHNICAL CHARACTERISTICS 5.1. SCOPE The coffee grinders are intended for businesses and communities where ground coffee must be used, or in small shops selling coffee. This grinder should only be used to grind coffee beans. Any other use is considered improper and dangerous.
  • Page 10 TECHNICAL CHARACTERISTICS 5.2. TECHNICAL DATA PKE 100 V 100 V 110 V 220 V 230 V 240 V 380 V 50 Hz 60 Hz 60 Hz 60 Hz 50 Hz 50 Hz 50 Hz Electrical Power Rotational 332,5 412,5 velocity Ø...
  • Page 11 TECHNICAL CHARACTERISTICS 5.2. TECHNICAL DATA E6 100 V 100 V 110 V 220 V 230 V 240 V 380 V 50 Hz 60 Hz 60 Hz 60 Hz 50 Hz 50 Hz 50 Hz Electrical Power Rotational 1.270 1.530 1.580 1.500 1.290 1.310...
  • Page 12 TECHNICAL CHARACTERISTICS 5.2. TECHNICAL DATA E8 100 V 100 V 110 V 220 V 230 V 240 V 380 V 50 Hz 60 Hz 60 Hz 60 Hz 50 Hz 50 Hz 50 Hz Electrical Power Rotational 1.270 1.530 1.580 1.500 1.290 1.310...

  • Page 13: External Components

    EXTERNAL COMPONENTS Hopper lid Coffee bean hopper Hand protector Break option stepped Hopper grind shutter Position indicator Setting roller hopper block LCD screen Grind regulator Refill button Upper portafilter holder Fork Exit chute adjustment screw Dose Lower button portafilter holder Refill button Coffee collection...

  • Page 14: Installation

    INSTALLATION 7.2. IMPORTANT WARNINGS 7.1. LEGAL NOTICES The operator must be a responsible The installer must read this instruction adult. Never a child nor someone without manual carefully before installing the the ability to accept that responsibility. machine. When handling the grinder, the following precautions should be obeyed: The installation of the device must be carried out by qualified...
  • Page 15 INSTALLATION 7.3. WHERE TO USE IT 7.4. INSTALLING THE COFFEE GRINDER Before connecting the coffee grinder, check the following: The appliance must be installed on a solid. flat surface. • The characteristics on the data plate must match those of the electrical The minimum size for the mains network.
  • Page 16 INSTALLATION ADJUSTMENT 8.1. GRINDER SET UP 7.5. TRANSPORT PROTECTION The installer must remove the Place the hopper ( ) on the grind regulator transport protection before installing the ) and make sure the bean trap ( ) is in machine. the closed position.

  • Page 17: Adjustment

    ADJUSTMENT Lock Embellisher Coarse Fine Unlock Fig. 1 Fig. 2 ORIGINAL INSTRUCTIONS | QUALITY PROCESS REF. | V. 09|10|2020 | CODE K07180...
  • Page 18 ADJUSTMENT 8.2. PK MODEL SUPPORT ADJUSTMENT The standard configuration is useful for For portafilters with diagonal wings, the most portafilters on the market. However, standard runners must be replaced by the depending on the geometry of each ones supplied separately. portafilter, it can be adjusted as follows for a good fit: Release the runners, for this, release...
  • Page 19 ADJUSTMENT Screw Portafilter spring clamp Fig. 3 ORIGINAL INSTRUCTIONS | QUALITY PROCESS REF. | V. 09|10|2020 | CODE K07180...
  • Page 20 ADJUSTMENT 8.2.1. SCALE CALIBRATION zeroing at the beginning of the process, due to the deformation properties of the load cell materials. Once the grinder has been installed in its normal position, calibrate the scale using the standard 200 g weight. Supplied with the machine.
  • Page 21 ADJUSTMENT 8.4. GRIND ADJUSTMENT SYSTEM Rotate the grind regulator ( ) until reaching the grind level desired. Rotating the grind regulator clockwise will result in a courser grind; turning the regulator counter clockwise will result in a finer grinder (Fig. 5). Once you reach the desired grinding point, Coarse you can fix the grinding regulation(...

  • Page 22: Operation

    OPERATION 9.1. MAIN SWITCH The main switch ( ) has the following positions: AUTOMATIC / OFF / MANUAL (Fig 7.3) I / 0 / II (Fig. 7.4) The equipment's electronic AUTOMATIC functions are activated Equipment off Equipment in manual mode. Backup system that allows the equipment to be used in the event of a fault in the power...
  • Page 23 OPERATION 9.2. 9.3. AUTOMATIC MODE Operating considerations. This allows 10 distinct portaportafilters or dispensing cups of different weights to Taring the Portafilter: be stored by assigning a distinct weight The grinder will respond to a minimum to each of them (improves workflow and weight by going into the tare state.
  • Page 24 OPERATION 9.6. INSTANT MODE 9.4. MANUAL GRIND MODE This operating mode allows you to use the In this operating mode, you can select weighing system manually. 1, 2 or 3 coffee doses by pressing the corresponding number icon on the LCD To do this, insert the portafilter or dosing screen once ( ).

  • Page 25: Settings

    SETTINGS The grinder settings descriptions are split saved portafilters: into two sections: SETTINGS / PORTAFILTER SETTINGS / • Setting the grinding times for one, DELETE Portafilter / PASSWORD: 0000 / two and three doses. DELETE HOLDER MEMORIES 1, 2, 3. / •...
  • Page 26 SETTINGS 10.2. THE GRINDER SETTINGS MENU To access the settings menu, press the icon . From the menu, you can use the ( and ) buttons and confirm an option using the . Press to go back one menu level. To exit the menu, press the button as many times as necessary to get to the...
  • Page 27 SETTINGS 10.3. ERROR MESSAGES AND stop. The display shows the message SOLUTIONS “GRINDING TIME EXCEEDED. REMOVE Portafilter”. Extra weight detected during grinder start-up: During the grinder’s start-up time, there must be no weight on the support, Portafilter not saved: in automatic mode, if it is turned on with the portafilter or the portafilter is not in the memory.
  • Page 28 ENGLISH ENGLISH ACTIVE FRANÇAIS FRANÇAIS ACTIVE DEUTSCHE DEUTSCHE AKTIV SET LANGUAGE ITALIANO ITALIANO ATTIVO PORTUGUESE PORTUGUESE ATIVA ESPAÑOL ESPAÑOL ACTIVO NUMBER OF DOSE 1 COFFEES TOTAL NUMBER OF COFFEES NUMBER OF DOSE 2 COFFEES NUMBER OF DOSE 3 (*) COFFEES NUMBER OF COFFEES VIEW NUMBER OF DOSE 1 COFFEES...
  • Page 29 01/01/2015 0000000 01/01/2015 0000000 01/01/2015 0000000 01/01/2015 0000000 01/01/2015 0000000 01/01/2015 0000000 NEW PASSWORD 0000 PASSWORD CHANGED TIME CHANGED DATE FORMAT CHANGED DATE FORMAT CHANGED DATE CHANGED kg. CHANGE BURRS 00500 kg ALARM CHANGED TARING PROGR. X WEIGHT ._g PROG. X SAVED REMOVE FILTER DELETE HOLDER MEMORIES 1, 2, 3 CALIBRATING...

  • Page 30: Cleaning

    CLEANING 11.1. GENERAL CLEANING the hopper safety screw ( ) and remove the grinder’s hopper by turning it a quarter turn anti-clockwise and pulling it upwards. The hopper ( ) can be cleaned with a To guarantee proper operation of the damp cloth or with soap and water to grinder, as well as good quality ground remove the oily residues produced by the...
  • Page 31 ( moistened with saline, distilled water or any product meant for touch screens. • Grind up all the Compak cleaning product to a medium fineness so it works properly. Turn off the machine and then wipe it •...

  • Page 32: Maintenance

    MAINTENANCE 12.1. GENERAL NOTICE 12.2. GENERAL MAINTENANCE Before performing any type of maintenance As well as the cleaning operations operation: described in the previous section, to ensure the grinder operates properly and to ensure the best quality of ground coffee, periodic •...
  • Page 33 MAINTENANCE 12.3. GRINDING GROUP MAINTENANCE / CHANGING BURRS Embellisher To perform grind chamber maintenance Lock please observe the following steps: Unlock Turn off the grinder by making sure the main power switch ( ) is on the OFF position. Disconnect the plug from the power source. Loosen the hopper security screw ( ) using a flat head screw driver as seen in (Fig.1)
  • Page 34 MAINTENANCE Loosen the propeller with Allen key H6. Tighten the extractor stud (Fig. 11) with a flat screwdriver until the lower burr carrier is released and removed. LOWER BURR CARRIER • Unscrew the three screws with the Philips PH2 screwdriver of the lower burr carrier.
  • Page 35 MAINTENANCE Clean the inside of the grinding chamber with a brush or vacuum cleaner and remove all coffee residues as well as residual lubricant from the threads of the upper burr carrier and the grind chamber. Open Close Position the extractor stud by loosening it by the lower part of the same holder and place the lower holder.
  • Page 36 MAINTENANCE 12.3.1. ADJUSTING THE PARALLEL SYSTEM Loosen the screws of the grinding regulator ( ) with the help of a Torx T20 screwdriver, according to (Fig.10.) For Point 0 grinder models with micrometric system PARALLEL, before removing the grinding regulator ( ), turn the regulating brake ( ) counterclockwise to free it from the PARALLEL fixing shoe.
  • Page 37 MAINTENANCE 12.4. REPLACEMENT OF METAL GRID stainless is possible. The grid is replaced without removing any screws. ENSURE PLACEMENT IN CORRECT POSITION. The exit grid ensures consistency in the dose. Located inside the coffee outlet ( ), it can be replaced by following the steps below: See 12.3.1.A section Remove the screws securing the plastic cover using an Allen key No.
  • Page 38 MAINTENANCE 12.5. BATTERY REPLACEMENT TAKE OUT On Demand models have a built-in battery back-up for saving operating information when the grinder is shut down. When this battery is spent, it must be replaced SET IN by another of the same characteristics CR2032 (Lithium Cell 3V).

  • Page 39: Declaration Of Conformity

    Molí Barri, Parcela B - Pol. Ind. Can Barri - 08415 Bigues i Riells - Barcelona - Spain Ph. 34 93 703 13 00 - Fax 34 93 703 13 23 - www.compak.es ORIGINAL INSTRUCTIONS | QUALITY PROCESS REF. | V. 09|10|2020 | CODE K07180...
  • Page 40 Ref. Quality process 002/03 | v.09/10/2020 | K07180    CONTACT Molí Barri, Parcela B PH: +34 93 703 13 00 Website: www.compak.es Polígono Industrial Can Barri Fax: +34 93 703 13 23 08415 Bigues i Riells Barcelona - Spain E-mail: info@compak.es...
