Compak PKE Instruction Manual page 33

12.3. GRINDING GROUP
MAINTENANCE / CHANGING BURRS
To perform grind chamber maintenance
please observe the following steps:
Turn off the grinder by making sure the
main power switch (
position. Disconnect the plug from the
power source. Loosen the hopper security
screw ( ) using a flat head screw driver as
seen in (Fig.1) and remove the hopper (
) from the grind regulator (
screws on the grind regulator (
Torx T20 screw driver following (Fig.10).
For the grinders with micrometric system
PARALLEL, before removing the grinding
regulator ( ), turn the grinding adjustment
brake ( ) counter-clockwise to release it
from the PARALLEL fixing shoe.
Rotate the upper holder
clockwise until it is removed
from its housing.
NOTE: These operations should
be done by a qualified service
tecnician.
ORIGINAL INSTRUCTIONS | Ref. quality process 002/03 | v. 12/02/2021 | K07173H01
) is on the OFF
). Loosen the
) using a
12.
MAINTENANCE
Lock
Unlock
Embellisher
Fig. 10
33
