Compak PKE Instruction Manual page 16

8.
REGULATION
8.2. ADJUSTING FORK PK
The serial configuration is valid for most
portafilter on the market. However,
depending on the geometry of each
portafilter, it is possible to proceed in the
following way for a correct adjustment:
1. Free portafilter spring clamp, for it
must release the screw that secures
the fork with the help of a screwdriver
(Fig. 3).
2. Portafilter spring clamp on the inside
has recorded an A and a B.
3. Once disassembled the portafilter
spring clamp, mounted in the opposite
direction to which came installed, i.e.
the A B position and vice versa. In this
Assembly the portafilter holder will enter
into the fork and will be fixed.
the position
Serial configuration
NOTA: In the case of PKE model, the fork is not adjustable.
16
Engraving
indicating
ORIGINAL INSTRUCTIONS | Ref. quality process 002/03 | v. 12/02/2021 | K07173H01
For portafilter with diagonal wings, the
standard spring clamp must be replaced by
those supplied.
Engraving
indicating
the position
Included with your
grinder
