Compak PKE Instruction Manual page 20

8.
REGULACIÓN
8.4. PREPARATION OF THE DETECTOR
HOLDER (OPTIONAL)
1. Place the detector on the double
portafilter (Fig. 1).
2. Check that the detector ring tab is
properly closed (Fig. 2).
3. Make sure that the arrow is in the
correct position on the lower side (Fig. 3).
Fig. 1
20
ORIGINAL INSTRUCTIONS | Ref. quality process 002/03 | v. 12/02/2021 | K07173H01
Fig. 2 Fig. 3
