Tools Required; Product Disassembly Process - HP ProCurve 9304m Product End-Of-Life Disassembly Instructions

2.0 Tools Required

List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Description
Phillips head screwdriver
Slotted tip screwdriver

3.0 Product Disassembly Process

3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. Remove the screws from the rear cover
2. Remove the rear cover
3. Unplug the fan assys
4. Unplug and remove PCBA #1
5. Remove the screws from PCBA #2
6. Remove PCBA #2
7. Unscrew the fan tray thumbscrews
8. Remove the fan tray
9. Remove the plastic rivets from the fan tray and rear cover
10. Remove the fans
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).
