Installing the HP KVM Server Console Switch G2

Overview

The HP KVM Server Console Switch G2 ships with rack-mounting brackets for easy integration into the
rack. Stabilize the rack in a permanent location before installing the equipment. Avoid uneven loading or
overloading of the rack cabinets.

Installation checklist

Before installation, refer to the following lists to be sure that all of the listed components were received.

Console switch kit contents

•
Console switch
•
Power cords
•
Rack mounting kit
•
Serial cable
•
Documentation kit
This kit might contain extra hardware for your convenience.

Required items not included

•
Interface adapters
One interface adapter is needed for each server or device.
USB
o
PS2
o
Serial
o
HP BladeSystem
o
•
UTP CAT 5 cable or higher

Required tools

The following tools are required for some procedures:
•
Phillips screwdriver
•
Cage nut insertion tool (included with your original rack hardware kit)
Installing the HP KVM Server Console Switch G2 6
