Specifications - iSystem IC57163 User Manual

Specifications

GENERAL
Supply voltage
Operating temperature
Storage temperature
Humidity
MECHANICAL
Size
Weight
OPERATION
Communication interface to Blue Box
Debug signal valid input voltage range
Power consumption
PROTECTION
Debug signals
DAP1-3 and DAPE1-3
DAP_RESET
VREF
9.0V DC via FNET cable
10°C to 40°C
-10°C to 60°C
5% to 80% RH
80 x 55 x 18 mm
0.125 kg
iSYSTEM proprietary FNET
3.3V (max. 3.6V)
Max. 1.5W (dependent on operation mode)
33Ω series termination/protection resistors,
ESD protection devices
10kΩ pull-down
1kΩ pull-up, 33Ω series termination/protection
resistor
1kΩ input impedance
4
