Specifications

GENERAL
Operating temperature 10°C to 40°C
Storage temperature
Humidity
MECHANICAL
Size
Weight
OPERATION
Communication
interfaces to PC
Supply voltage
Power consumption
ELECTRICAL
Debug signal valid
input voltage range
Debug signals
All inputs except the
TDO
TDO input
TMS and TDI debug
signals
RESET
TAR_VREF (target
reference voltage) pin
-10°C to 60°C
5% to 80% RH
122 x 127 x 45 mm (W x D x H)
approx. 500g
USB 2.0, 10/100 Mbps Ethernet
10V to 24V DC
< 8W
1.8V to 5.5V DC
47 series termination/protection resistors, ESD protection devices.
Depending on the specific debug adapter, termination might be
different from 47 on some critical signals.
10 kOhm pull-up resistor
10 kOhm pull-down resistor
10 kOhm pull-up resistor
1 kOhm pull-up resistor, buffer-driven to prevent current flow into an
unpowered iC5000 from a powered target board
100 kOhm input impedance
