Installation and Operation
"Apply Changes" (F) for the certificates to be used.
E
F
A
B
C
Figure 3-97. HTTPS Setup

Help

The Help menu provides access to the user manuals and
documents, the About
Documents screen.
Figure 3-98. Help

About Screen

See 3-99. This screen displays information about
Figure
the Power Zone system such as hardware and firmware
versions, external storage and the current status of
communication ports. The About screen also provides
the ability to reboot the Connectivity Server.
42
D
screen, and the Upload
007632

Upload Documents Screen

See 3-100. The Upload Documents screen can
Figure
be used to either provide translated Power Zone Owner's
Manuals or documentation like wiring diagrams for
storage and use on the Connectivity Server. Only PDF
files are currently supported.
To select a file from a mobile device:
Select "Local File" tab (A).
1.
Select "Choose" (B).
2.
Select a file from your mobile device.
3.
To select a file from a USB drive attached to the
Connectivity Server:
Select "USB on Panel" tab (C).
1.
009622
Select "List Packages".
2.
Select a file.
3.
To upload the file as a manual:
Select the file and choose the "Manuals" radio
1.
button (D).
Select from the "Manual List" dropdown (E).
2.
Select the language of the manual (F).
3.
Select "Upload file" (G).
4.
To upload the file as a document:
Select the file and choose the "Documents" radio
1.
button (H).
Select from the "Documents" dropdown, or type a
2.
new document name for the uploaded file.
Select the language of the document (F).
3.
Select "Upload file" (G).
4.
Owner's Manual for Power Zone Connectivity Server
Figure 3-99. About Screen
