The connection can be initiated in two ways:
2.
– Left mouse click on the menu item "Connect
using" "Access Point" (B).
– Right mouse click on the device that represents
the Connectivity Server (A) and select "Connect
using" "Access Point".
Figure 3-72. Initiate Connection
A "Connection Successful" message will be
3.
displayed.
See 3-73. A network connection between
4. Figure
the devices has been established and the
Connectivity Server has assigned an IP Address
(A).
Figure 3-73. Assigned IP Address
Launch the web browser on the connected device
5.
and go to http://192.168.25.1. Allow 20-30 seconds
for the Power Zone Application to load.
The Connectivity Server can now be accessed
6.
using the web browser on the connected device.
Change Connectivity Server Bluetooth Name
See 3-74. Select the text box field and
1. Figure
enter a new name (A).
Select "Apply Changes" (B).
2.
Owner's Manual for Power Zone Connectivity Server
B
A
Confirmation of name change is displayed.
3.
See
4.
name text box (A).
009727
Unpair Bluetooth Device
Unpairing from the Connectivity Server will break the
network connection between the two devices. After
unpairing, the procedure in
A
Zone App on Web Browser of Connected Device
be performed once again to establish a network
009728
connection between the two devices.
See
1.
device (A).
Select "Disconnect" (B).
2.
Installation and Operation
Figure 3-74. Change Bluetooth Name
3-75. New name is now displayed in
Figure
Figure 3-75. Updated Bluetooth Name
Connect and View Power
3-76. Select connected Bluetooth
Figure
A
B
009721
A
009721
must
