Alternator Detail Screen

See 3-26. The Alternator Detail Screen displays
Figure
bargraphs of measured alternator parameters. In some
cases the readings will be empty if the associated
sensors are not fitted. The alternator screen also
provides a button to access the Alternator Settings
screen. This screen allows editing of alternator related
configuration parameters.
Figure 3-26. Alternator Detail Screen
Alternator Settings
See 3-27. The Alternator Settings screen displays
Figure
an icon for each entry on the left side of the screen. Click
on the text field on the right and enter a new value. The
new value is entered and saved. If the value is out of
range a red warning will display and prevent saving of
data. The range will be displayed above the keyboard
entry as shown in
Figure
Figure 3-27. Alternator Settings
16
3-19.

System Detail Menu

The System Detail menu provides access to the alarm
history, event history, shutdown bypass alarm log, run
times, maintenance remaining, nameplate data, dealer
information, system notes and utility screens.
Alarms and Warnings
See
Figure
displays only active and present alarms and warnings.
A warning (A) is considered active when the condition for
the warning is present. A warning is low severity and
does not need to be acknowledged.
007534
An alarm or shutdown alarm (B or C) is considered active
when an alarm condition is or was present, but the alarm
has not yet been acknowledged. An alarm is high
severity and must be acknowledged. A shutdown alarm
is highest severity and must be acknowledged. The
generator will not operate when a shutdown alarm is
present.
Alarms and Warnings are displayed with their respective
icons to the left. The top text displays the date that the
Alarm or Warning occurred. The bottom text displays the
type of message, the associated function code and the
value that caused the alarm to trigger.
NOTE: The displayed value is the value at the time the
fault is triggered, not the setpoint for the condition.
A
007540
B
C
A
B
C
Figure 3-28. Alarm and Warning Icons
See 3-29. Press the "Acknowledge All" button (A)
Figure
to acknowledge all active alarms. Once pressed, the
icons for all active alarms with present conditions will turn
white, and all other alarms will be removed from the list.
NOTE: This does not apply to warnings.
007535
Owner's Manual for Power Zone Connectivity Server
3-28. The Alarms and Warnings screen
Warning - Yellow (!)
Alarm - Red (!)
Shutdown Alarm - Dark Red (x)
