Installation and Operation

Screen Layout

See 3-5. The screen is divided into the
Figure
(A), the
Banner Bottom Banner
screen information area in the center (C). The top and
bottom banners are displayed on every screen.

Top Banner

A B
(A) Keyswitch Status
A red LED indicates the key is in the OFF position. A
green LED indicates the key is in the AUTOMATIC
position. An orange LED indicates the key is in the
MANUAL position.
(B) Communications Health
A blinking green LED indicates the Main Controller is
responding to Modbus requests. A blinking red LED
indicates the Main Controller is not responding to
requests.
(C) Generator Name
Displays the name of the generator. The user can give
the generator an easy to understand name such as
"East", "West" or "Number 1". See
the generator, go to Setup
Manager screen, press the Edit button (A) and enter the
Friendly Name.
10
Top
(B), and the main
Figure 3-6. Top Banner Features
3-7. To name
Figure
Communications Device
A
C
B
Figure 3-5. Screen Layout
C D
A
Figure 3-7. Edit Generator Name
(D) Run Hours
Displays the total number of hours the generator has
been run.
