Installation and Operation
represents a 100% duty cycle. The output duty
cycle is the analog or control value divided by the
PWM counts value. In this example, a control value
of 33 divided by the PWM counts of 100 would
result in a 33% duty cycle.
The Computed PWM Frequency (G) will be
6.
displayed.
Check the "Enable" checkbox (H) to enable the
7.
output.
Check the "Invert" checkbox (I) to invert the signal
8.
if required. For example, if the duty cycle is 75% it
will change to 25%. A duty cycle of 100% will invert
to full off. Only PWM outputs can be inverted.
Select "Apply Changes" (J).
9.
NOTE: PWM outputs share pins with digital outputs and
both should not be enabled at the same time.
A
B
C
D
E
F
G
H
I
J
Figure 3-64. PWM Type Output

Communications

The Communications screens are used to configure the
external network connections to the Connectivity Server
(Ethernet, Wi-Fi and Bluetooth). You can view the
modules present on the internal Modbus RTU network
through the Device Manager and configure Email
messaging and Modbus Pass-through (TCP or RTU).

Wi-Fi and Ethernet Port Setup

Static IP Address Configuration for Ethernet
See 3-65. Navigate to
1. Figure
Communications
In the "Connection mode" setting, select "Static"
2.
(A).
This mode is selected to assign an IP address
3.
(IPv4) to the Ethernet interface (B).
30
(E) Setup
Ethernet/Wi-Fi/Bluetooth.
IPV4 Address, Subnet, DNS and Gateway (C) are
4.
set to match the requirements of the host network.
Click "Apply Changes" (D).
5.
A
B
C
D
Figure 3-65. Static IP Address Configuration for Ethernet
Dynamic IP Address Configuration for Ethernet
See
1.
Figure
Communications
Click Ethernet interface (A).
2.
In the "Connection mode" setting, select "Dynamic"
3.
(B). This mode is selected to obtain an IP address
via DHCP.
Click "Apply Changes" (C).
4.
Once an IP address has been assigned, the IPV4
5.
address and MAC address of the interface is
007572
displayed.
A
B
C
Figure 3-66. Dynamic IP Address Configuration for
Wireless LAN Client Setup - Search and Connect
to Access Point
See
1. Figure
existing client mode connection, the SSID of the
currently connected Wi-Fi network will be displayed
following the text "Connected To". If there is no
Owner's Manual for Power Zone Connectivity Server
Navigate to:
3-66.
Ethernet/Wi-Fi/Bluetooth.
Ethernet
3-67. Select "Client" (A). If there is an
007573
Setup
