existing client mode connection, the SSID of the
most recently connected Wi-Fi network will be
displayed following the text "Current saved profile".
Select "Country Code" (B) to match the country the
2.
Client mode will be present in.
Click the drop down menu for Channel ID (C).
3.
The channel with the least interference will be chosen
when selecting Auto, otherwise the channel ID selected
will be used for providing Wi-Fi service. The list of
channels will change according to the country selected
as each country has its own list of supported channels.
Default Wi-Fi network name is Power Zone HotSpot. The
name can be changed by selecting the text box (D) below
"Channel ID".
Select/Deselect
4.
broadcast/not broadcast the SSID of the client.
When not selected, the SSID will not be broadcast
over the air. The user will have to manually enter
the SSID in their Wi-Fi Client set up to connect to
the client.
WPA2 will be automatically selected as the security
5.
protocol to be used for Client connections.
A password must be entered to connect to this
6.
access point (G). Password can be shown in plain
text or hidden by clicking on the "Show Password"
box next to the password.
Click "Apply Changes"
7.
Connectivity Server in Client mode with the
settings selected.
A
B
C
D
G
H
Figure 3-67. Wireless LAN Client Setup
Wireless LAN Client Setup - Manual Connection
to Access Point
The Wi-Fi IP address will be assigned by the Wi-Fi
network. Static IP addresses are not supported for Wi-Fi
connections.
Owner's Manual for Power Zone Connectivity Server
"Broadcast SSID"
(H) to place
E
F
See
1. Figure
checkbox (A).
Enter SSID (Service Set Identifier) (B).
2.
Enter network password (C) as required by
3.
network configuration.
Click "Connect" (D) to connect to wireless network.
4.
Status message will be displayed after clicking
5.
"Connect".
(E) to
A
B
C
D
Figure 3-68. Wireless LAN Client Setup
the
Hotspot Mode
See
1. Figure
(A).
Select "Country Code" (B) to match the country the
2.
HotSpot mode will be present in.
Click the drop down menu for Channel ID (C).
3.
The channel with the least interference will be chosen
when selecting Auto, otherwise the channel ID selected
will be used for providing Wi-Fi service. The list of
channels will change according to the country selected
as each country has its own list of supported channels.
Default Wi-Fi network name is Power Zone HotSpot. The
name can be changed by selecting the text box (D) below
"Channel ID".
Select/Deselect
4.
broadcast/not broadcast the SSID of the hotspot.
When not selected, the SSID will not be broadcast
over the air. The user will have to manually enter
007575
the SSID in their Wi-Fi Client set up to connect to
the hotspot.
WPA2 will be automatically selected as the security
5.
protocol to be used for HotSpot connections.
A password must be entered to connect to this
6.
access point (G). Password can be shown in plain
text or hidden by clicking on the "Show Password"
box next to the password.
Installation and Operation
3-68. Click the "Manually Enter Wi-Fi"
3-69. Check the "HotSpot" radio button
"Broadcast SSID"
007576
(E) to
