14
|
Technical data
Installer reference guide
54
Symbol
AC*, CN*, E*, HA*, HE*, HL*, HN*, HR*,
MR*_A, MR*_B, S*, U, V, W, X*A,
K*R_*, NE
D*, V*D
DB*
DS*
E*H
FU*, F*U, (for characteristics, refer to
PCB inside your unit)
FG*
H*
H*P, LED*, V*L
HAP
HIGH VOLTAGE
IES
IPM*
K*R, KCR, KFR, KHuR, K*M
L
L*
L*R
M*
M*C
M*F
M*P
M*S
MR*, MRCW*, MRM*, MRN*
N
n=*, N=*
PAM
PCB*
PM*
PS
PTC*
Q*
Q*C
Q*DI, KLM
Q*L
Meaning
Connection, connector
Diode
Diode bridge
DIP switch
Heater
Fuse
Connector (frame ground)
Harness
Pilot lamp, light emitting diode
Light emitting diode (service monitor
green)
High voltage
Intelligent eye sensor
Intelligent power module
Magnetic relay
Live
Coil
Reactor
Stepper motor
Compressor motor
Fan motor
Drain pump motor
Swing motor
Magnetic relay
Neutral
Number of passes through ferrite core
Pulse-amplitude modulation
Printed circuit board
Power module
Switching power supply
PTC thermistor
Insulated gate bipolar transistor (IGBT )
Circuit breaker
Earth leak circuit breaker
Overload protector
CVXM20+FVXM25~50A2V1B
Split system air conditioners
4P625991-1 – 2020.06
