6 Unit installation

In this chapter

6.1 Preparing the installation site

6.1.1 Installation site requirements of the indoor unit

CVXM20+FVXM25~50A2V1B
Split system air conditioners
4P625991-1 - 2020.06
6.1 Preparing the installation site ................................................................................................................................................
6.1.1 Installation site requirements of the indoor unit ..................................................................................................
6.2 Opening the indoor unit .........................................................................................................................................................
6.2.1 To remove the front panel.....................................................................................................................................
6.2.2 To remove the front grille......................................................................................................................................
6.2.3 To open the terminal block and remove the electrical wiring box cover .............................................................
6.3 Mounting the indoor unit.......................................................................................................................................................
6.3.1 To install the indoor unit........................................................................................................................................
6.3.2 To drill a wall hole ..................................................................................................................................................
6.3.3 To remove the slit portions....................................................................................................................................
6.3.4 To provide drainage ...............................................................................................................................................
6.4 Mounting the user interface ..................................................................................................................................................
6.4.1 To mount the user interface holder ......................................................................................................................
Do NOT install the unit in places often used as work place. In case of construction
works (e.g. grinding works) where a lot of dust is created, the unit MUST be
covered.
Choose an installation location with sufficient space for carrying the unit in and out
of the site.
WARNING
The appliance shall be stored in a room without continuously operating ignition
sources (example: open flames, an operating gas appliance or an operating electric
heater).
INFORMATION
Also read the precautions and requirements in the
precautions" [ 4
INFORMATION
The sound pressure level is less than 70 dBA.
NOTICE
The equipment described in this manual may cause electronic noise generated from
radio-frequency energy. The equipment complies to specifications that are designed
to provide reasonable protection against such interference. However, there is no
guarantee that interference will not occur in a particular installation.
It is therefore recommended to install the equipment and electric wires in such a
way that they keep a proper distance from stereo equipment, personal computers,
etc.
Install power cables at least 1 m away from televisions or radios to prevent
interference. Depending on the radio waves, a distance of 1 m may not be
sufficient.
5].
