Daikin CVXM20A2V1B Installer's Reference Manual page 27

CVXM20+FVXM25~50A2V1B
Split system air conditioners
4P625991-1 – 2020.06
Floor-standing installation
a
a
b
e
a
6‒1 Indoor unit installation drawing: Floor-standing installation
A Front view
B Side view
C Top view
a Screw hole 6×
b Left-back piping hole location
c Right-back piping hole location
d Left/right piping hole location
e Left-bottom piping hole location
f Right-bottom piping hole location
1 Drill a wall hole, depending on which side piping is taken out. See
drill a wall hole" [ 4
2 Open the front panel and remove the front grille (see
4
unit" [ 25]).
3 Remove the slit portions using nippers. See
4
portions" [ 31].
4 Secure the unit to the wall and floor using 6 screws M4×25L (field supply).
6×
5 When the complete installation is finished, attach the front panel and the
front grille in their original position.
A
a
a
c
C
f
a
31].
6 Unit installation
|
B
d
(mm)
"6.3.2 To
"6.2 Opening the indoor
"6.3.3 To remove the slit
Installer reference guide
27
