Electrical installation

8 Electrical installation
In this chapter

8.1 About connecting the electrical wiring

8.1.1 Precautions when connecting the electrical wiring

Installer reference guide
40
8.1 About connecting the electrical wiring ..................................................................................................................................
8.1.1 Precautions when connecting the electrical wiring ..............................................................................................
8.1.2 Guidelines when connecting the electrical wiring ................................................................................................
8.1.3 Specifications of standard wiring components .....................................................................................................
8.2 To connect the electrical wiring to the indoor unit ...............................................................................................................
8.3 To connect optional accessories (wired user interface, central user interface, wireless adapter, etc.)..............................
Typical workflow
Connecting the electrical wiring typically consists of the following stages:
1 Making sure the power supply system complies with the electrical
specifications of the units.
2 Connecting the electrical wiring to the outdoor unit.
3 Connecting the electrical wiring to the indoor unit.
4 Connecting the main power supply.
DANGER: RISK OF ELECTROCUTION
INFORMATION
Also read the precautions and requirements in the
precautions" [ 4
INFORMATION
Also read "8.1.3 Specifications of standard wiring
WARNING
▪
All wiring MUST be performed by an authorised electrician and MUST comply
with the applicable legislation.
▪
Make electrical connections to the fixed wiring.
▪
All components procured on-site and all electrical construction MUST comply
with the applicable legislation.
5].
"2 General safety
4
components" [ 42].
CVXM20+FVXM25~50A2V1B
Split system air conditioners
4P625991-1 – 2020.06
