4) IR remote MODE:
The laser can be controlled by the IR remote control:
• Press the FUNC-button until the display shows: "REM".
• Press the ENTER-button to confirm your choice.
Note:
In any standalone mode (excepted REM and SLA), press ON/OFF for 2 second to activate remote
function.
Remote control details:
Button
Sound sensivity
5) DMX512 MODE:
The laser can be controlled by any standard DMX-controller in 2 different DMX-modes:
• 1 CHANNEL MODE: for extremely easy setup and use! (display shows "1Ch")
• 17 CHANNEL MODE: for full control of all possibilities. (display shows "17c")
• Connect the DMX input of the laser to the DMX output of the previous unit in the chain or directly to the
DMX-output of your controller.
• Press the FUNC-button until the display shows: "1C" or "17C".
JB SYSTEMS®
AUTO SHOW
MUSIC SHOW
LASER ON/OFF
COLOR
EFFECT PAUSE
CHANGING PATTERN
SOUND SENSIVITY
FIXED PATTERN (FROM 1 TO 48)
PATTERN REPEATING
function
ON/OFF
In any other standalone mode except SLAVE: press 2s to
AUTO
Sound activated show, the blue is flashing when the
MUSIC
In sound activated mode, press music+B+1to9 to change
COLOR
To change the color from red to green or red & green
CHANGING
PATTERN
CHANGING
FIXED
PATTERN
PATTERN
Last pattern and current pattern cycle repeating
REPEAT
Description
In REM mode: turn on/off the laser.
turn on the REM mode
Auto running show
sound is detected.
the sensitivity settings
To show and change patterns
You can select one pattern from 1 to 48
