Summary of Contents for JB Systems Sirius
- Page 2 DANGER ~ GEVAAR ~ GEFAHR ~ PELIGRO ~ PERIGO WARNING: DANGER! never expose the lens to direct sunlight, even for a short period. This may damage the light effect or even cause fire! ATTENTION: DANGER! n'exposez jamais la lentille directement aux rayons de soleil, même pendant un bref instant.
-
Page 3: Before Use
ENGLISH USER MANUAL ENGLISH USER MANUAL SAFETY INSTRUCTIONS: OPERATION MANUAL CAUTION CAUTION: To reduce the risk of electric shock, do not remove the top cover. No user-serviceable parts inside. Refer servicing to qualified service personnel only. ® Thank you for buying this JB SYSTEMS product. -
Page 4: Overhead Rigging
ENGLISH USER MANUAL ENGLISH USER MANUAL OVERHEAD RIGGING 3. BUTTONS MENU To select the programming functions Important: The installation must be carried out by qualified service personal only. Improper DOWN To go backward in the selected functions installation can result in serious injuries and/or damage to property. Overhead rigging requires To go forward in the selected functions extensive experience! Working load limits should be respected, certified installation materials ENTER... - Page 5 ENGLISH USER MANUAL ENGLISH USER MANUAL Show 3 (Sh 3): Fixture is placed on a podium, in front of the audience. The spot is always Tilt Inversion Normal: Tilt movement is not inversed. projecting to the audience’s direction; i.e. in front of the stage. Pan movement angle (left to right to Tilt inversion: tilt movement is inversed left): 160°.
- Page 6 ENGLISH USER MANUAL ENGLISH USER MANUAL Please also check the chapter about the DMX-channel configuration of the unit to find out how you can force Electrical installation for two or more units in DMX-master/slave: a reset by DMX. In this mode the units will show a synchronized show, working to the rhythm of the beat but you can still control some functions on the master by 1 or 4 DMX-channels.
-
Page 7: Maintenance
ENGLISH USER MANUAL ENGLISH USER MANUAL OPERATE THE UNIT BY CA8 OR RF8SET Pin layout XLR-5pin: Pin1 = GND ~ Pin2 = Negative signal (-) ~ Pin3 = Positive signal (+) ~ Pins4+5 not used. To prevent strange behavior of the light effects, due to interferences, you must use a 90Ω to 120Ω When used in standalone or master/slave mode we strongly advise you to use the CA-8 “Wired easy terminator at the end of the chain.
