ENGLISH
o
Sop
o
Sou
o
So1
o
So2
o
So3
• Press the ENTER-button to confirm your choice.
You can connect several LASERs together: just put the first unit of the chain in one of the sound activated
effect modes and all other units in "Slave mode" (display shows "SLA") to make them all work in perfect
sync!
Note: When no music is detected, the laser output will be shut off (blackout).

2) FULL AUTOMATIC MODE:

The laser automatically runs a preprogrammed sequence. Select this mode when only 1 laser is used
(standalone) or when the laser is placed as the first (master) unit in a chain with several lasers.
• Press the FUNC-button until the display shows one of the following: Sop Aut, Aup, 17C, 1C, Sla or
REM.
• Now use the UP or DOWN buttons to select:
o
Aut
o
Au1
o
Au2
o
Au3
o
Aup
• Press the ENTER-button to confirm your choice.
The laser automatically runs a preprogrammed sequence.
You can connect several SMOOTH SCAN-3 Mk2 LASERs together: just put the first unit of the chain in
one of the automatic effect modes and all other units in "Slave mode" (display shows "SLA") to make them
all work in perfect sync!

3) SLAVE MODE:

The laser follows the instructions given by the first SMOOTH SCAN-3 Mk2 LASER (master) in the chain.
• Connect the DMX input of the laser to the DMX output of the previous laser in the chain.
• Press the FUNC-button until the display shows "SLA"
• Press the ENTER-button to confirm your choice.
You can connect several lasers together. Please put the first unit of the chain in "Music or automatic
mode" and all other units in "Slave mode" (display shows "SLA" to make them all work in perfect sync!
JB SYSTEMS®
(Sound activated random show, containing pattern and grating effects)
(Sound activated shows in RGY colors)
(Sound activated show in red color)
(Sound activated show in green color)
(Sound activated show in yellow color)
(Automatic shows in RGY colors)
(Automatic shows in red color)
(Automatic shows in green color)
(Automatic shows in yellow color)
(automatic random show, containing pattern and grating effects)
6/12 SMOOTH SCAN-3 Mk2 LASER
USER MANUAL
