5.5 Operation parameters

This device allows the coniguration of the parameters listed in the following table.
The parameters marked with the symbol
Settings remain active even after the device has been turned off and they are stored in non-volatile memory.
PRINT MODE
AUTOFEED
CHARS / INCH
CODE TABLE [NUM]
FONT TYPE
D
are the default values.
Printing mode:
Normal D = enables printing in normal writing way
Reverse = enables printing rotated 180 degrees
Setting of the Carriage Return character:
CR disabled = carriage Return disabled
CR enabled D = carriage Return enabled
Font selection:
A = 13 cpi, B = 17 cpi
A = 17 cpi, B = 22 cpi D
CPI = Characters Per Inch
Identiier number of the character code table to use.
See the paragraph 8.10 to learn about the character tables corresponding to the iden-
tiication numbers set with this parameter.
The character tables set with this parameter are the same set with the command 0x1B
0x74 (refer to the commands manual of the device).
The numeric value of the identiier is made up with the following two parameters for the
setting of two digits for the tens and the units:
Code Table [num x 10]
Code Table [num x 1]
Setting of the font type:
International D = Enables the use of the 256 characters font tables
Chinese GB18030 = Enables the use of the chinese extended font GB18030-2000
Korean CP949 = Enables the use of the korean font CP949
When the "International" font is enabled, you need to choose the character code table
("Code Table" parameter). When the Chinese or Korean fonts is enabled, the selection
of the character code table is suspended ("Code Table" parameter).
Setting the digit for tens:
0 D 2 4
1 3 5
Setting the digit for units:
D
0 2 4 6 8
1 3 5 7 9
